Physical specifications
1. High inflation speed, suitable for small enterprises, reduce labor costs
2. Simple, convenient and quick operation, can be used on the table, can produce different specifications of air cushion film
3. The machine is light, the noise is very low, easy to store, can save a lot of storage space
product parameters
| Model | Power | Voltage | Working speed | Temperature range | Speed range | Air volume range | Material axis diameter | Air channel size | Outline dimension | Weight of machine | Film width & length |
| P(W) | V(V) | S(m/min) | grade | grade | grade | D(mm) | C(mm) | (L*W*H)mm | W(kg) | mm | |
| XD-PACK 100 | 200 | 110-220 | 10 | 100-270 | 20-100 | 0-200 | 50.8 | 18-20 | 480*290*360 | 5.5 |
air pillow 200/250/300mm Length 300m air bubble 400/600mm Length 300m |
| XD-PACK 300 | 450 | 110-220 | 28 | 70-150 | 0-100 | 0-100 | 50.8 | 18-20 | 500*390*420 | 18 |
air pillow 200/250/300mm Length 300m/500m/700m air bubble 400/600/800mm Length 300m/500m |
Advantages of air cushion machine
1 Perfect sealing
The sealing edge is complete and not easy to fold and air leakage, high-speed air flow will not affect the sealing of plastic film.
2 Full air filling
Professional air filling process, air filling rate can reach 95%,high-speed and strong air flow will support.
3 Stable and Reliable
The defect rate is less than 0.1%. can work contunouly more than 48 hours. and easy to change spare parts.
4 Fast and Multifunction
Machine running speed is 28m/minutes, air filling speed belongs to the leading of industry level.
