Physical specifications
1. With unparalleled inflation rate, it can be operated according to a simple diagram
2. We can make the buffer film specification produced by XINDA , reduce the packaging weight and reduce the transportation cost
3. nstant online production saves 90% storage space
product parameters
Model | Power | Voltage | Working speed | Temperature range | Speed range | Air volume range | Material axis diameter | Air channel size | Outline dimension | Weight of machine | Film width & length |
P(W) | V(V) | S(m/min) | grade | grade | grade | D(mm) | C(mm) | (L*W*H)mm | W(kg) | mm | |
XD-PACK 100 | 200 | 110-220 | 10 | 100-270 | 20-100 | 0-200 | 50.8 | 18-20 | 480*290*360 | 5.5 |
air pillow 200/250/300mm Length 300m air bubble 400/600mm Length 300m |
XD-PACK 300 | 450 | 110-220 | 28 | 70-150 | 0-100 | 0-100 | 50.8 | 18-20 | 500*390*420 | 18 |
air pillow 200/250/300mm Length 300m/500m/700m air bubble 400/600/800mm Length 300m/500m |
Advantages of air cushion machine
1 Perfect sealing
The sealing edge is complete and not easy to fold and air leakage, high-speed air flow will not affect the sealing of plastic film.
2 Full air filling
Professional air filling process, air filling rate can reach 95%,high-speed and strong air flow will support.
3 Stable and Reliable
The defect rate is less than 0.1%. can work contunouly more than 48 hours. and easy to change spare parts.
4 Fast and Multifunction
Machine running speed is 28m/minutes, air filling speed belongs to the leading of industry level.
